Batch Retort sterilizer, Autoclave sterilizer, Food sterilizer, Food sterilization process retort
high temperature batch retort sterilizer
high pressure Autoclave sterilizer

Batch retort sterilizer, Food autoclave sterilizer

Steam water spray batch retort, batch autoclave sterilization particular

All in one : Single autoclave sterilization for all heat resistant and waterproof package material

Save Energy45% : Steam didn't exhaust, Energy 100% use up, Least cooling water

Protein Glucose protector : Excellence thermal exchange function, best nutrition preservation

Water Steam Spray retort sterilizer for sterilization process

spray
Water spray retort
cy3000h
Retort sterilizer
cy3000f
Autoclave
rotary motion
Rotary retort
R&D
Pilot autoclave

Brief presentation of steam water spray batch retort, batch autoclave sterilization

  1. steam water spray batch retort design principle (basic theory): a. thermodynamic : steam & vapor & saturate water at two phase balance response b. hydrodynamics : fluid mechanics at nozzle pressure spray function c. aerodynamic : air flow turbulator
  2. hundreds high efficient spray nozzle, it's suitable arrange by the long axle and radial axle of sterilizer
  3. all nozzles spray out the high pressure water at same time.
  4. high temperature steam directed inject into the sterilizer.
  5. injection steam direct heating the circulation water.
  6. circulation pump drive water from bottom to the top of retort chamber, water spray out again, circulation water be heating again, temperature smooth rise up cycle by cycle
  7. our " steam water spray " autoclave sterilization its keep temperature precision at ±0.5°C ( ±1.0°F)and save energy 45%

Best solution for food sterilization and medical sterilization process

Description the function of batch retort, batch autoclave sterilization

Basic function

  1. the function of batch retort sterilizer
  2. working temperature : between 80°C(175°F) ~ 130°C(265°F)
  3. over pressure :.......... max 4kg/cm2 (57psi)
  4. equipment style:.........Static retort and rotary retort (static autoclave , rotary autoclave)
  5. thermal medium :........Soft water and high temperature steam
  6. heating process:.........direct heat exchange into the retort chamber (don't need heat exchanger)
  7. cooling process:
    1. circulation cooling - with heat exchanger for cooling circulation (aseptic cooling circulation)
    2. direct cooling - ....... city water direct cooling the product into the autoclave chamber
  8. batch retort max working volume :
    1. static batch retort: ......... max working volume from 820 liters/batch to 10900 liters/batch
    2. rotary batch autoclave: ... max working volume from 800 liters/batch to 3800 liters/batch
    3. R&D autoclave sterilization max working volume 30 liters, 50 liters, 70 liters

Go Top .

What we can do, with single batch retort sterilizer

Food sterilization process ( food sterilization retort sterilizer )

Sterilization process container package material:

(for all heat resistant package material : heat resistant over 125℃ / 25mins and should be waterproof)

  1. Food sterilization process
    1. Flexible retort pouch sterilization
      1. Plastic retort pouch, non-pvc retort pouches, laminated film retort pouch, laminated film bag, retortable pouch, standing retort pouch, vacuum retort bag
      2. Aluminum foil retort pouches, aluminum foil packaging bag, aluminum laminated bag
      3. Nylon asepsis pouches, nylon pouches
      4. Soft can sterilization process
      5. Leafage package food
      6. Poultry retort pouches sterilization
    2. Glass bottles and glass jar and glass container sterilization
      1. Glass bottles with cap, eight-square glass bottle
      2. Glass jar
      3. Glass can
      4. Amber Glass Bottle
    3. Plastic bottles and plastic cup and plastic tray sterilization
      1. PP bottles, PP cup with film seal, PP tray
      2. HDPE bottles, HDPE tray, HDPE cup
      3. Nylon bottle, nylon cup, nylon tray
    4. Metal can and metal bottle sterilization
      1. Tin can sterilization, two piece tin can, three piece tin can
      2. tin can with print or not print
      3. Aluminum bottle, aluminum can
  2. Pharmacy autoclave sterilization and medical sterilizing and sterilize medical tools
    1. Injection drop batch autoclave sterilization
      1. Flexible pouch injection drop sterilization, drop bottles sterilization
      2. Injection drop (250~500 cc) autoclave sterilization
      3. Glass bottle injection drop sterilization
      4. Amber Glass Bottle sterilizing, amber glass bottle leak testing equipment
      5. Leak testing, leaking test autoclave sterilizer, leak testing retort sterilizer
    2. Medical tools and pharmacy batch autoclave sterilization
      1. Laboratory tools sterilizing
      2. Glass bottle injection drop sterilization
      3. Amber Glass Bottle sterilizing, amber glass bottle leak testing equipment
      4. Oral dose autoclave sterilizer
      5. Contact lens sterilizing process and autoclave sterilizer
      6. Medical treatment tools sterilization
      7. Health food sterilization
      8. Biotechnology production sterilization
      9. Leak testing, leaking test autoclave sterilizer, leak testing retort sterilizer

Go Top .

Contact

Home

Autoclave sterilizer

Sterilization process

Food sterilization

Sterilization pouches

Sitemap

Used Retort

About us

Exhibition

Trade service & Business

Technology service (Free charge service)

  1. High temperature sterilization enquiry service
    1. Food sterilize retort (autoclave) process
    2. Pharmacy (medical) sterilize process, and leak testing process
    3. Equipment and tools sterilizing process
    4. Sterilization F value setup enquiry
    5. G.M.P / HACCP / F.D.A high temperature sterilization process enquiry
  2. R&D testing service ( we had a R&D batch retort, it's service for our customer
    1. Free charge: sterilize testing of retort food with steam water spray R&D sterilization batch retort
    2. Supply retort pouch bag for testing, its free charge
    3. Supply aluminum retort pouch bag for testing , it's free too

Business and enginery service

  1. Business service
    1. Trade currency : NTS, USD, EUR
    2. Delivery : FOB / C&F
  2. Enginery service
    1. Technician stay duration : two person, stay 7 days
    2. Hand book : English and Chinese traditional, local language should translate by customer
    3. Technician installation guide service, if need the translator is pay by customer
    4. Equipment start and running testing
    5. Operation and maintenance train
    6. Sterilization process testing and confirm batch retort sterilization function
    7. Equipment is one year guaranty
